Descriere produs Sursa ASUS ROG LOKI 850W 80+Platinum

Sursa ASUS ROG LOKI 850W 80+Platinum Intel Form Factor SFX-L ATX 3.0 Yes Dimensions 125 x 125 x 63.5 mm Efficiency 80Plus Platinum Protection Features OPP/OVP/UVP/SCP/OCP/OTP Hazardous Materials ROHS AC Input Range 100-240Vac DC Output Voltage +3.3V +5V +12V -12V +5Vsb Maximum Load 20A 20A 70.8A 0.8A 2.5A Combined Load 110W 110W 850W 9.6W 12.5W Total Output 850W Connectors MB 24/20-pin x 1 CPU 4+4-pin x 2 PCI-E 16-pin x 1 PCI-E 8-pin x 3 SATA x 6 PERIPHERAL x 4 Package Contents Power Cord x 1 Motherboard Power Cable x 1 (450mm) CPU Cable x 2 (550mm) PCI-E Gen 5 16-pin Cable x 1 (450mm) PCI-E 1-to-1 Cable x 1 (450mm) PCI- E 1-to-2 Cable x 1 (450mm) SATA 1-to-3 Cable x 2 (300+200+100mm) Peripheral 1-to-4 Cable x 1 (300+100+100+100mm) Addressable RGB Cable x 1 (800mm) User Manual x 1 ATX to SFX adapter bracket x 1 Weight 1.815kg (single PSU) AURA SYNC ARGB 0dB Fan Button No Cybenetics Noise Level Certification A

Specificatii produs:

Starea produsului Nou

Producator ASUS

Greutate 2.6 kg

Number of fans 1 fan(s)

Purpose PC

80 PLUS certification 80 PLUS Platinum

Illumination Yes

Fan diameter 12 cm

Peripheral (Molex) power connectors (4-pin) 4

PSU Type SFX-L

Conectivitate Full - Modular

Iluminare RGB Da

Certificare 80 Plus 80 PLUS Platinum

Efficiency 80Plus-Platinum

Modular Yes

Combined power (+5Vsb) 12.5 W

Max output current (+5Vsb) 2.5 A

Number of SATA power connectors 6

CPU power connector (4+4 pin) Yes

Combined power (-12V) 9.6 W

Max output current (-12V) 0.8 A

Motherboard power connector 24-pin ATX

Cabling type Fully-Modular

Combined power (+3.3V) 110 W

Max output current (+3.3V) 20 A

Max output current (+5V) 20 A

CPU power cable length 55 cm

PCI Express power connectors (16-pin) 1

Combined power (+5V) 110 W
